Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines (1910)
Linch, Charles Sutterley, b. 1869 · Boston, American Steam Gauge and Valve Mfg. Co. · leaf 79
Run No. 3ASteam 130 Ford Rec. 21 Aft. Rec. 21 Vac. 24V Rev. 130I. H. P., F. H. P. 394.S I. H. P., F. L. P. 34S.0 I.H.P., A. H.P. 397.5 I. H. P., A. L. P. 33S.S Total, I. H. P. 1479.1Throttle wide open. Gear same as Run 1A. 74 MARINE INDICATINGSeries 1 … Run No. 4ASteam 126 Ford Rec. 22 Aft. Rec. 22 Vac. 25 Rev. 130I. H. P., F. H. P. 401.2 I. H. P., F. L. P. 370.51. H. P., A. H. P. 378.4 I. H. P., A. L. P. 343.8 Total, I. H. P. 1493.9 Throttlewide open. Gear F. H. P. linked in If. A. H. P. linked in 1£.F. L. P. linked full out. A. L. P. linked full…
Indicators for steam-engines · Marine engines
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
