Babendreier, Arthur O. [from old catalog], Maryland institute for the promotion of mechanic arts and design, Baltimore. [from old catalog] · Baltimore, Md., The Maryland institute for the promotion of mechanic arts and design · leaf 23
izontal, the reverse ofthe above would be true. The two methods for finding power and pressure are:one the application of the parallelogram of forces and theother by the application of trigonometry, or the relationof the sides of the triangle, i. e., the length of inclined sur-face, the vertical… … 20 Elementary Mechanics ter of gravity. The weight W in lbs. may be repre-sented by the length of a vertical line W-E as theresultant of the parallelogram; the two sides of such 3 parallelogram Wx and Wymay be found readily, theformer being parallel to theplane and the latter at rightangles…
Mechanics
