Babendreier, Arthur O. [from old catalog], Maryland institute for the promotion of mechanic arts and design, Baltimore. [from old catalog] · Baltimore, Md., The Maryland institute for the promotion of mechanic arts and design · leaf 45
\ 2nd driver ^2=16, 2nd driven, d3= 123rd driver, ^4=12, and 3rd driven, ^5=10;to find the number r.p.m. n\ of machinespindle? Then by substituting in the formula nX^X^X^4 =^1X^1X^3X^5; the r.p.m. and the diameters of thevarious pulleys, the condition would be … 42 Power Transmission 80X36X16X12 = niXI2nX 12X10 , 80X36X16X12 __. , and f^ = =384 r.p.m. for the machine. If the r.p.m. n and fti are givenand it is desired to provide a pulley-train to satisfy the speed ratio, anumber of combinations with dif-ferent diameters may be used, pro-vided the product…
Mechanics
