Babendreier, Arthur O. [from old catalog], Maryland institute for the promotion of mechanic arts and design, Baltimore. [from old catalog] · Baltimore, Md., The Maryland institute for the promotion of mechanic arts and design · leaf 72
lume. Theunit pressure on any intermediate plane will be propor-tional to its depth below the water surface. Figs. 27-A-B-C-D-E show tanks of various shapes, inwhich d is the large diameter and dx the small diameter;h is the total height in feet from the bottom to the watersurface, and hi the… … The diameters, d, are equal in each case; so, too, thediameters, d\, are equal to eachjDther. 70 Pressure The head, A, in feet is the same in each caseAlso the head, hi, in feet is the same in each case. If P represents the unit pressure in lbs. per square inchat the bottom and Pi the unit pressure…
Mechanics
