Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 103

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 103
cts as a piston.Steam is admitted to thischamber by means of a by-pass. The tendency wouldbe to force out the piston,and so draw the ends of thepipe closer together, but asthe steam in the pipe and in the chamber is of the same total pressure,each force neutralizes the other, and the joint is…

Mechanical movements
