Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 107

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 107
ring is obtained. 252. Vertical section, showing details of the parts. 253. ROTARY STEAM ENGINE. A cylindrical piston A,with wing abutments C, C, A double cam block H, made adjustable by a set screw and with exhaust ports at Kand I. A steam port through the cylindercover and a curved passage in the… … 254. ROTARY ENGINE. Recesses are formed in tne pistonhaving an S-shaped partition between them, the recesses opening at opposite ends of the piston intothe steam chests, and by means ofports into an annular space be-tween the casing and piston. Thepiston has an eccentric portionwhich has a perfect…

Mechanical movements
