Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 116

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 116
EXPLOSIVE MOTOR POWER AND APPLIANCES. 115 … 269. ALCO-VAPOR BOILER and three-cylinder engine. Alcoholof low grade is injected into the pipeboiler and converted into vapor un-der pressure by the heat of part ofthe vapor burned under the boiler.The three cylinders are single actingon a single crank. Casing of boileris removed to show its…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
