Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 126

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 126
293- CENTRIFUGAL PUMP. German type. The revolving disk receives the water on eachside near the shaft in curvedchannels, and discharges throughopenings in the periphery of thedisk opposite to a continued slotin the casing. A corrugated clos-ure of the shell and disk near theshaft prevents back flow… … 126 HYDRAULIC POWER AND APPLIANCES. 294. RIVER MOTOR. Wheels and chain paddles set in a
