in supplementary exhaust ports. The piston valves are connected to and operated by the following piston. The exhaust is discharged into STEAM POWER APPLIANCES. 79 the main trunk of the engine through the hollow spool valves andfrom the ports opened by the trunk pistons into the jacketed…
