Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 215

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 215
547. AUTOMOBILE STEAM EN-GINE. A two-cylinder engine of thelocomotive type with Hnk motion and Dvalves ; cylinders 2 J x 4 inches. Boilerpump operated by a lever and link froma crosshead of one of the cylinders.Extreme cut-off o to f. The sprocket wheel on the shaft be-tween the eccentrics connects…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
