cylinder is bolted to the end of the frame and is supportedindependently. The guides are formed in the frame itself andthe frame is formed into a complete circle at both ends of theguides to give greater strength and stiffness. In some heavyduty frames, the part forming the guides is made separate… … 30 STEAM ENGINES The frames of vertical engines are usually A-shaped, as shownin Fig. 19. In the larger sizes they are made in two parts, theupper part or guide section being in one piece and bolted to thelower part or housing. The bottom of the frame is usually arectangle in shape to permit it to…
