Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 253

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 253
E ■: with 660. BICYCLE BALL BEARING, hourglass separating rollers. The balls havethree points of pressure contact, two on thecone and one on the cup. The separating rollers are carried by aguide ring frame. … 661. BALL-BEARING CAS-TOR. The rolHng sphere A isheld in position by the sheet met-al case E. About 40 small ballsare arranged to circulate under thebearing plate B, guided and heldin place by the case C. The ballstraverse around the annularspace D. 662. SPRING MOTOR. A series of coiled springs and…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
