Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 259

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 259
nd the specimen cutshows a few of the designsthat such a machine is ca-pable of producing. Thef^ sectional head contains theclamp device for holding thework. The tool U mayhave from one to four pointslike a chasing tool to varythe design of the work. His the work in the chuck andR the cam or rose… … HOLLOW DRAW IN 3PIN0LECONE / ^BEARING

Mechanical movements
