Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 264

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 264
SECTION XVI. HOROLOGICAL, TIMEDEVICES, ETC. 261 Section XVI.HOROLOGICAL, TIME DEVICES, ETC. … 691. ELECTRIC PENDULUM. P P is the pendulum, W a weight,mounted on a lever, W C A. W C A can move about a center, C, and is at present prevented from turn-ing by the catch, S S. When P Pswings to the right, the lowerscrew in P P passes under E (seeside view Z) and frees W C A.W C A, under the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
