Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 288

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 288
741. MACHINE-MADE CHAINS. Samples of the complex operation ofmodern machine work. Not only chainsof various patterns, but hooks and eyes,and almost every conceivable form ofwire work and punch and press work isnow done by machinery. … 742. SUSPENDING GRIP in a shaft or betweentimbers. The toothed sectors, a, grip the rock ortimbers. The upper figure is for a definite sizedopening with a pivoted clevis at c. 743. The lower figure for a variable sized shaftor opening. The toothed arms, h, h, and lockingclevis makes a convenient…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
