Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 298

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 298
782. DOWN-DRAUGHT GAS-MELTINGFURNACE. The burner B, of combined gas and air,enters the flame at the top of the crucible and dis-charges to the chimney below the bottom of the cruci-ble at H. E is the cover Hfted by the lever C, andchains to swing off the furnace. The hearth is aperforated fire tile… … 783. OIL OR GAS FIRED*-*<Air FORGE. Oil or gas enters the ato-mizer by the small pipe and is mixed atthe nozzle by a strong blast of air. Ad-ditional air jets to complete the com-bustion enter beneath the bed of thefurnace.

Mechanical movements
