Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 372

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 372
es are jointed, as shown,and to each of them is fixed aframe in which a weight, D,moves. When any spoke is in ahorizontal position, the weight,D, in it falls down, and pullsthe weighted arm. A, of the thenvertical spoke straight out, bymeans of a cord, C, going overthe pulley, B, to the weight…

Mechanical movements
