Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 375

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 375
thelower pulley, whence the same weightsreascend in a straight direction to theupper pulley. The weights of the endless chain running or falHngdown in the curvilinear direction of the periphery of the drum are morenumerous than those that are raised up in a straight line, because thecurvilinear… … 927. PERPETUAL MOTION. Revolving tubes and balls. Theballs, A and B, are in equilibrium because they are at an equal distance from the vertical line that passes throughthe center E. By the construction of themachine, the ball, D, being, on the con-trary, more distant from the point of sup-port than…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
