Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 378

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 378
ey can move independent ofthe frames, B, and wheels, G.While the frames, B, makeone revolution, the wheels, D,and the center w^heels make two revolutions. This is caused by theaction of the weighted levers E. Their weight, or inertia^ prevents themfrom passing around the center of the axis of the… … 938. PERPETUAL MOTION. Mercurial wheel. A is the screwturning on its two pivots; B is a cistern to be filled above the level of the lower aperture of the screwwith mercury; D is a reservoir,which, when the screw isturned round, receives themercury which falls from thetop. A pipe conveys the…

Mechanical movements
