Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 55

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 55
ON OF POWER, STEAM. 76. DOWN DRAUGHTBOILER FURNACE.Hawley type under a Heinboiler, c, tubular grate, d^tube connection betweengrate header and front drum.b. tube connection betweengrate header and rear drumwith blow off. a, uptake connectionfrom each end of grate header to shell of boiler. This…
