Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 71

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 71
70 GENERATION OF POWER, STEAM. 136. NOVEL SURFACE CONDENSER. A cylinder filledwith small tubes as shown in the section, 137. A spray jet of water … To Distiller thrown against the tubes at one end, and with a large volume of air, isdrawn through the tubes by a suction blower at the end of the conicalchamber. The water is vaporized and with the air takes up the heat ofthe exhaust steam and is discharged in a vapor by the blower. Thepump keeps…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
