Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 70

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 70
tby gravity or pressure.The weight of the wateralternately filling thechambers, carries themdown and opens a steamport in the axial valve tothe boiler pressure, whenthe water flows into the boiler by gravity. At the same time theupper chamber is being filled by the condensation of its steam. It… … 68 GENERATION OF POWER, STEAM.
