Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 85

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 85
valvesis presented, where E is the exhaustvalve and S the steam valve. Thesteam valve, of the double-ported bal-anced type, is held within the exhaustvalve E, but is not set exactly in the center of the latter valve, sothat it is held in position by steam pressure. The usual vacuum dash-pots are… … v/z/z/z/y////////////

Mechanical movements
