Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 97

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 97
DASHPOT GOVERNOR. The eccentric is mounted on aplate G, pivoted at P, and is connected to E B, No. i, and E B, No. 2, by connecting rods in such a manner thatthe action of centrifugal force in throwingthe weights B B outward cause the centerof the eccentric to swing toward the centerof the shaft.… … STEAM POWER APPLIANCES. 97

Mechanical movements
