Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 120

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 120
ng air and gasolinethrough the valve E, whichalso covers the gasoline in-lets on the face of the valveseat and is connected withthe annular chamber, ^,and pipe, d. The gaso-line feed is regulated bythe needle valve a. Otherdetails and exhaust pas-sage are shown in the hor-izontal section, 274. 275-… … Ii8 EXPLOSIVE MOTOR POWER AND APPLIANCES.
