Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 137

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 137
JFOR EMPTYING NO. ITANK EMPTYINGTANK CraCIQ TRAVELIN8 SHEAVE Sri … 324. COUNTERBALANC-ING HYDRAULIC ELEVA-TORS. Showing the arrange-ment of valves, cylinder, circulat-ing pipe for up and down motionof the hydraulic piston and thedistribution of the counterweightsto equalize the power. The de-tails of operation are shown by thelettering on the cut. HYDRAULIC POWER…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
