Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 138

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 138
as shown inthe cut, 326, inserting it and push-ing it down in the bottom of thewell, 328, and boring out the sandwith a sand auger, 327. A drive-strainer tube may also be drivenand the sand drawn by an auger.Strainer points are also used anddisconnected near the bottom ofthe well. The supply of… … of chamber and held open by the lever and weight L, with its move-ment adjusted by the springs above and below the lever. D, discharge 136 HYDRAULIC POWER AND APPLIANCES. valve. G, a chamber with elastic heads or diaphragms of thin cor-rugated metal, for an air chamber and to prevent hammer. K,…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
