Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 199

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 199
FOOT TREADLE 489. FEATHERINGBLADE PROPELLER.A foot-power propellerwith paddle blades to-y^^ hang over the sides at the/\ stern, or may be placed incouBSE^^F^PADDLE ^n cxtenslon at the stern,as shown in the cuts.The longest movement ofthe paddle is when it isimmersed, and the pad-dle being vertical,…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
