Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 202

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 202
e d driven by compressed air contained in the cylindrical tank i; m, twoscrew propellers driven in opposite directions by reversing bevel gears tokeep the torpedo from turning over ; h, shaft ; g, /, steering-apparatusconnections from electric steering gear, a, b, c; k, fuse ; /, explosivecharge ;… … E, storage battery; F, oil and water tanks; G, compressed air cham-bers ; H, gun-cotton shell in the aerial torpedo gun; J, magazine; K,Whitehead torpedo and tube ; L, trimming tank, oil and gasoHne tank atH under the bow. In the Holland submarine boat the gasoline engine and the dynamoare directly…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
