Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 193
ldiameter, forming three concentric rings, nearly touching.The upward-pointing end of each set of tubes is expandedinto a long steam-chamber, one to the right, another to theleft of the stack. The 21 tubes of the inner rings are bent,below, away from the two outer ring rows, so that betweenthe… … xix a VXIX <uA be s SATURATED AND SUPERHEATED STEAM. 187 the form of the inner ring and goes to right and left of thesmoke-chamber up above the exhaust tips, so that the entiresuperheater, nearly up to the ends of the pipes which areexpanded into the steam space, is inclosed in an iron…
Locomotives
