Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 233

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 233
598. CAR COUPLER. Washburn type.Has the side movement of the draw bar, andalso a movement of the head of the couplercontrolled by the side thrust of the helicalsprings for centering the coupler head. … 599. BULLDOZER PRESS. Forquickly bending straps and braces ofiron or steel for car and other construct-ive work. In this way a large numberof forming blocks are used of differentdesigns to fit the slides of the machine. 599A. HAND-CARDRIVEN BY MOTOR-CYCLE. The s% hp.motorcycle is mountedon a…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
