Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 134

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 134
463. LINK OR CONNECTINGROD, with adjustable brasses. Keysinside and outside of pins. 463a. STAKE PULLER. — Aneasy way to pull stakes and posts. Aclevis to pinch the stake or post againstthe end of the lever with the leverpivoted to the foot post. 463&. STALK PUL-LER. — The conicalspiked drums…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
