Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 238

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 238
GEARING AND GEAR MOTION, ETC. 235 … 607. INTERRUPTING CAM-GEAR MO-TION. B, the driver. The motion of A isfrom fast to slow or slow to fast, with a momen-tary stop as the long teeth match at C and C.The stop motion is governed by the form of thecurves of the long teeth at C and C.

Mechanical movements
