Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 240

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 240
GEARING AND GEAR MOTION, ETC. 237 … 616. PARALLELISM FROM CIR-CULAR MOTION. A central pulleywhich is stationary and belted to a pulleyof the same size, but loose on an arm re-volving around the stationary pulley, willhave an indicator arm on the movingpulley always in the same direction. An idler pinion on the arm between twoequal…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
