Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 240

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 240
onary pulley, willhave an indicator arm on the movingpulley always in the same direction. An idler pinion on the arm between twoequal gears will also produce the sameeffect on revolving the arm and indexwheel around the central gear wheel. 617. CIRCULARLY VIBRATING MOTION. A ring plate pin-ioned to… … 618. DIFFERENTIAL SPEED GEAR. A speed gearing in whicha center pinion driven at a constant rate of speed drives directly and at different rates of speed a seriesof pinions mounted in a sur-rounding revoluble case orshell, so that by turning theshell one or another of thesecondary pinions may…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
