Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 27

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 27
9. TRANSMISSION of powerby wire rope and anchored levers.The braced tee pieces A B, withtheir arms connected with a distantrocker by the wire W W, pivotedto the windmill frame and to thecrank rod at A, make a very effec-tive method of operating a pumpat a distance. A strong fencewire is sufficient… … lo. BAG ELEVATOR. The bagsare delivered from a car door on to agrating through which the forked handsof the elevator picks them up and dis-charges upon an inclined chute gratingto slide to a horizontal carrier from whichthey are deposited at any desired place.The forked hands are braced loosely…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
