Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 284

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 284
volving stirring arms drivenby the gear and center shaft throughthe conical center standard of thetank. The amalgamated plates ormercury rests on the bottom of thetank. m, f, perforations in the disk car-rying the stirring arms, for equal dis-tribution of the ore sHmes upon themercury bed. 731.… … rope to lead fromthe rear wheel tothe knucklesheaves, and per-mit of additionalroom at the top. This front wheel has one or more grooves, dependingupon the number of cars to the trip and the amount of material to behauled, and has always one less groove than the larger or rear wheel, thesheaves…

Mechanical movements
