Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 302

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 302
lted. The pinions meshing into the segmentsare driven through gear trains from a 26 horse-power electric motor.An additional tilting device is provided, consisting of a vertical hy-draulic cylinder at either side, with their plungers linked to pins pro-jecting from the sides of the mixer vessel… … 789. HOT-METAL MIXER. Tilting type. The hot-metal mixershown in the cut is designed for a capacity of 275 tons of fluid metal. The maximum external dimensionsof the containing tank are about15 feet diameter and 27 feet length.The shape is cylindrical, with aconical pouring spout at the frontend,…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
