Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 345

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 345
877. POTATO-RASPING MA-CHINE. Used in the manufacture ofstarch, a, hopper ; b, barrel rasp ; c,receptacle for pulp ; d, wooden buffer ;e, setting screw ; /, water jet. The buffer is for adjusting the open-ing between the rasping barrel anditself to insure a uniformly fine potatopulp. 878.… … vines. 879. AUTOMOBILE MOWING MACHINE. McCormick type.The motor is a double cylinder, lo-horse-power gasoline engine. The oil tank is dividedinto three compart-ments : one for oil,one for batteries, andone for water. Poweris transmitted fromthe motor by sprocketwheels and chain toa friction…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
