Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 353

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 353
lest arm of its kind to take apart, as all of the bolt and magazine ^^^^ mechanisms can be dis- .;/^A;/;.-/:i;^--j^-4/ mounted and againassembled withoutthe use of a singletool. The magazine holdsfive cartridges, which can be held in reserve by turning the cut-off down;the gun can then be used as a… … MISCELLANEOUS DEVICES. 351 one continuous motion, which operation withdraws the empty cartridgecase from the chamber and ejects it from the gun. The top cartridgein the magazine then rises in front of the bolt, if using magazine fire, ora cartridge is dropped in front of the bolt by hand, if using…
