The inventor's universal educator : An educational cyclopaedia and guide for inventors, patentees, manufacturers, mechanics and all others connected directly or indirectly with patents (1906)
Dieterich, Fred G., 1858-1923, comp · Washington, D.C. : F. G. Dieterich · leaf 125
ways. A B indicatesboiler, E, engine, F, crank disk, G, power transmitting wheel, D, dynamo, belted with wheel G H, electric heatercoil in boiler, I, electric heater circuit, and A, a bunson or other burner. The idea is to generate steam in the boilersufficient to operate the dynamo, after which… … 120
Patents · Mechanical movements
