Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 60

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 60
sea-sons ; I is a safety valve;K is a pressure gauge, andL is a water gauge. Diameter of top 9 feet;45 square feet of silveredglass surface. Boiler of blackened copper 31 inches high, 11 inchesdiameter. Thin glass cover 2 inches larger than boiler. Pressure generated 75 lbs. per square inch ; 11… … ^^^^^^^^^^^^^^5555S» 58 GENERATION OF POWER, STEAM.
