Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 65

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 65
E Plan and section of the crude oilburner used on theSouthern Cali-fornia Raihoad.This burner hasbut two chambers, oil andsteam; the air enters the fur-nace through graduated open-ings around the burner. 103.104. Mouth of burner.Plan of burner. 62 GENERATION OF POWER, STEAM. … 105. BURNER FOR AUTO-BOIL-ER. The disk chamber is stamped out ofplate iron. The interior air tubes arescrewed into the back head and furnish airto complete combustion. The outer tubesare screwed into the top plate and furnishan annular stream of vapor gas from thechamber below. 106. AUTOMOBILE…
