Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 65

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 65
ate and furnishan annular stream of vapor gas from thechamber below. 106. AUTOMOBILE BOILER. Showing the arrangement ofburner and vaporizing coil above the burner tubes. The gasohne is fed to andvaporized in the spiral coil. Thevapor injected into the burnerchamber by the valve B carriesair with… … 107. FUEL OIL BURNER. Plan and sections of the crudeoil burners used on the locomotives of the Southern Pacific Railroad.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
