Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 67

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 67
ghs, a, a, a, containing the liquid fuel, the discharge of which is regulatedby small basins, r, r, r, that communicate withthe troughs at b, b. Through the basins passdischarge pipes, T, T, T, open at each ex-tremity. All the parts of the grate are of ironcast in a piece, and comprising no… … GENERATION OF POWER, STEAM. 65
