iston b at full pressure, but the crank to cyhnder A is on the quarterwhere it moves at its highest speed, while the piston B moves down.It will also be seen that lower piston A reaches the top of its cylinder.At the same time, but instead of being in a position to exhaust as inthe upper one, it… … 147. HIGH SPEED VERTICAL EN-GINE. Rhodes type. Valve of the gridironbalanced type, with valve gear of a novel de-sign giving a quick and full movement of thevalve through a rawhide disk, H, rolling on anirregular cam on the shaft and made adjustablefor time of cut off between the limit of ^/g…
