Fig. 384 shows in skeleton the arrangement of levers by which thevalves are driven. Motion is obtained in the first place from aneccentric on the crank-shaft which is connected by its rod to avertical rocker-arm, QRS. Attached to the rocker-arm is the hookrod or lever FS which drives the…
