Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 80

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 80
ENGINE. Showing Corlissvalves on low-pressure cylin-der, direct connected wristplates, one for each cylinderto operate the steam valveswhile the exhaust valves areall connected by link rods,which are in turn directlyconnected to the eccentricrod. Valve gear of both cyl-inders have trip hooks… … 152. CORLISS EN-GINE. C. & G. Coopertype with double wrist plate.The governor controls theaction of the steam valvesby adjustable trip hooks anddashpots.

Mechanical movements
