Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 85

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 85
air of low-pressure piston, as the sleevein question slides into the high-pressure cylinder and both pistons canbe moved forward together and out of the cylinders. The valves are connected by a rod passing through a pipe betweenthe steam chests of the high-pressure and low-pressure cylinders.… … VALVE IN OPENING POSITION

Mechanical movements
