Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 114

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 114
261. ROTARY ENGINE. Casadays pat-ent. A reversing rotary with adjustable cut off.A is the cut-off plug within an adjustable rotablecylinder and operated by an arm and connectingrod to the eccentric or the plug rotated bysprocket and chain. D, reversing plug. H, abut-ment block, cushioned by steam… … 262. REVERSIBLE ROTARY EN-GINE. The piston when revolving in thedirection of the arrow takes steam by thethrow of a two-way cock; steam enteringthrough the diagonal slots in the abutmentpieces at /, /, and exhausting through theports e, c. Reversed by throwing over thesteam-cock opening to the…

Mechanical movements
